Product parameters

Input format: 12 mono + 4 stereo inputs
Channel EQ: 3-band mono EQ with sweepable mid; 4-band stereo EQ
Buses: 4 groups and 4 AUX sends
Effects / media: 24-bit DSP with scene presets, Bluetooth and USB recording/playback
Phantom power: Individually switchable +48 V on microphone channels
Frequency response: 20 Hz–40 kHz (+0/−1 dB); 20 Hz–60 kHz (+0/−3 dB)
THD+N: 0.01%
Microphone preamp S/N: 103 dB
Equivalent input noise: −126 dBu
EQ frequencies: High 12 kHz; mid 2.5 kHz; sweep 100 Hz–4 kHz; low 80 Hz

The MICKLE GM20 is built for live sound teams that need a wide analog control surface, fast channel access, and a practical master section for events and venues.

Applications

Live soundRental systemsEvent production

Send Inquiry

Mixer guides and resources

Compare Analog Mixers

Browse the complete MICKLE AUDIO analog mixers range and compare formats for your application.

Ask about OEM and ODM options

Share your target market, required format, branding, and order quantity for this professional analog mixer.
